Manila Rope
Manila Rope
1. Material: 100% natural jute
2. Size: to be customized
3. Color: red, yellow, black, blue, green, pink and others
4. Features: strict quality control, excelsior technological requirements, longer work life
5. Applications: shipbuilding, ocean transportation, national defense, military industry, sea petroleum, harbor operation, etc.
6. Packing: Packaged with bags, standard export carton or by customer requirments
7. Our advantages: quality assurance, experienced staffs, professional service, competitive price, etc.
8. Certifications: GL, ABS, CCS, ISO, NK, BV, LR, DNV, RS, etc.
9. Notes: Special specification and marks can be made according to customers requirements
10. Parameter table:
dia:mm | dia:mm | cir:mm | weight:kg/220m | mbl:kgf or tons |
4 | 5/32 | 1/2 | 3.00 | 190kgf |
5 | 3/16 | 5/8 | 4.00 | 240 |
6 | 7/32 | 3/4 | 6.40 | 285 |
7 | 1/4 | 7/8 | 7.70 | 370 |
8 | 5/16 | 1 | 11.90 | 545 |
9 | 11/32 | 1-1/8 | 14.00 | 620 |
10 | 3/8 | 1-1/4 | 15.00 | 705 |
12 | 1/2 | 1-1/2 | 23.10 | 1.07 |
14 | 9/16 | 1-3/4 | 30.80 | 1.46 |
16 | 5/8 | 2 | 41.80 | 2.03 |
18 | 3/4 | 2-1/4 | 48.40 | 2.44 |
20 | 13/16 | 2-1/2 | 48.40 | 3.25 |
22 | 7/8 | 2-3/4 | 60.50 | 3.66 |
... | ... | ... | ... | ... |
