Towing and Tugger Winches
Towing and Tugger winches:
1. For all types of tugs and offshore vessels,also combined with cable lifters. Product range from 5-150 tons.
2. Towing drum, declutchable and with band brake.
3. Automatic/mechanical spooling device
4. MOORING WINCH friction cluth and spindle band brake are hydraulically remotely controlled, manual operation of the spindle band brake also possible at the winch. The friction cluth assures that in every possible towing situation the drum can be disengaged without endangering the operative driving components.
5. Warping head fixed on the intermediate shaft.
Main technical specification:
Rated Pull(kN) | Rated Speed(m/min) | Drum Capacity(m) | Motor Power(kW) |
5 | ≥12 | Ф8х100 | 3/1.2 |
10 | ≥12 | Ф10х150 | 4.3/1.7 |
20 | ≥12 | Ф15х150 | 8.5/3.5 |
30 | ≥15 | Ф17х150 | 11/11/7.5 |
40 | ≥15 | Ф18х150 | 16/16/11 |
50 | ≥15 | Ф20.5х150 | 22/22/16 |
75 | ≥15 | Ф26х200 | 30/30/22 |
80 | ≥15 | Ф26х200 | 30/30/22 |
100 | ≥15 | Ф30х200 | 45/45/30 |
125 | ≥15 | Ф30х200 | 45/45/30 |
160 | ≥15 | Ф32х250 | 60/60/45 |
200 | ≥9.6 | Ф41х250 | 60/60/45 |
250 | ≥9.6 | Ф44.5х250 | 60/60/45 |
315 | ≥7.8 | Ф52х250 | 60/60/45 |
400 | ≥7.8 | Ф56х250 | 85/85/64 |
450 | ≥7.8 | Ф56х250 | 85/85/64 |
500 | ≥7.8 | Ф58х250 | 85/85/64 |
560 | ≥6 | Ф64х250 | 85/85/64 |
600 | ≥6 | Ф64х250 | 85/85/64 |
650 | ≥6 | Ф70х250 | 85/85/64 |
1000 | ≥4 | Ф85х250 | 85/85/64 |
1200 | ≥4 | Ф95х250 | 120/120/90 |
1500 | ≥4 | Ф95х250 | 150/150/72 |
1800 | ≥4 | Ф95х250 | 150/150/72 |
2000 | ≥4 | Ф100х250 | 180/180/135 |
