Aluminum Fire Extinguisher Cylinder
Aluminum Fire Extinguisher Cylinder
Aluminum Fire Extinguisher Cylinder is made of high strength Aluminum Alloy 6061, reliable on durability, fracture tough, it has resistance to tearing and cracking. This high-quality, high-performance aluminum fire extinguisher cylinder is widely used around the world.
We have CE, EN3, EN1869, EN694, EN671 and AS/NZ approvals for our products. All of our products are manufactured and tested under the standard of ISO9001, CE, EN3, etc. We also could provide OEM service to meet customer’s special requirements. For example, we can print customer’s company name or logo on the cylinder neck.
Product Details:
Place of origin: Chongqing, China (Mainland)
Brand name: HI-SEA
Material: aluminum alloy
Temperature range: -30 centigrade degree to +55centigrade degree
Color: red/ blue/ or other customized color
Model number: 2-7KG
Main Parameter:
CO2 fire extinguisher | 2KG | 2.3KG | 3KG | 4KG | 4.5KG | 5KG | 6KG | 7KG | |||
Out-diameter(mm) | 114 | 114 | 114 | 133 | 152 | 152 | 152 | 152 | |||
Volume(L) | 3 | 3.5 | 4.5 | 4.5 | 6.72 | 7.5 | 9 | 10.5 | |||
Cylinder length(mm) | 420 | 470 | 600 | 450 | 510 | 570 | 650 | 745 | |||
Cylinder weight(kg) | 4.9 | 5.6 | 6.8 | 7.2 | 7.55 | 8.55 | 10.4 | 10.85 | |||
Min wall thickness(mm) | 4 | 4 | 4 | 4.5 | 5 | 5 | 5 | 5 | |||
Max working pressure | 16.8bar | ||||||||||
Test pressure | 25bar | ||||||||||
CO2 filled weight | 2(-0.1) | 2.3(-0.12) | 3(-0.15) | 3(-0.15) | 4.5(-0.22) | 5(-0.25) | 6(-0.6) | 7(-0.35) | |||
Note: We Can Supply Various Fire Extinguisher Cylinder with Different Parameter As Requested | |||||||||||
