DIN Bronze Globe Valve
DIN Bronze Globe Valve
1. Type: Straight Type, Angle Type.
2. Nominal Diameter: DN15-DN100
3. Valve Body Material: Bronze
4. Valve Disc Material: Bronze
5. Gland Packing: Asbestos-free
6. Bonnet Gasket: PTFE
7. Hand Wheel: Cast Iron
8. Specification:
DIN Bronze Globe Valve - Straight Type | DIN Bronze Globe Valve - Angle Type | ||||
IMPA Code | Nominal Diameter | Face to Face L | IMPA Code | Nominal Diameter | Face to Face L |
755121 | 15 | 70 | 755131 | 15 | 65 |
755122 | 20 | 80 | 755132 | 20 | 70 |
755123 | 25 | 90 | 755133 | 25 | 75 |
755124 | 32 | 105 | 755134 | 32 | 90 |
755125 | 40 | 120 | 755135 | 40 | 100 |
755126 | 50 | 140 | 755136 | 50 | 105 |
755127 | 65 | 180 | 755137 | 65 | 115 |
755128 | 80 | 200 | 755138 | 80 | 125 |
755129 | 100 | 230 | |||
