JIS MARINE VALVE

Marine Cast Steel Globe Valve JIS F7313 20K :

1.Test standard:JISF7400.

2.End standard:JISB2220.

3.End type:Flange.

4.PN:20k.

5.DN:32mm-250mm.

6.Main material:

• Body/Bonnet:ZG230-450;
• Seat:SS410/BC6;
• Stem:SS410/H62;
• Disc:SS410/BC6.

7.Application:Oil piping,water piping and steam piping.

8.Function:Such valves are used for on-off duty and regulating the flow rate.

9.Specification of Marine Cast Steel Globe Valve JIS F7313 20K :

Size	L	Flange diam. (D)	Pitch (C)	Hole (nxd)	t	H	Weight
(mm)	(mm)	(mm)	(mm)	(mm)	(mm)	(mm)	(kgs)
32	190	135	100	4xΦ19	18	270	14.4
40	200	140	105	4xΦ19	18	290	16.0
50	230	155	120	8xΦ19	18	305	21.6
65	270	175	140	8xΦ19	20	345	30.4
80	300	200	160	8xΦ23	22	385	43.5
100	350	225	185	8xΦ23	24	440	62.3
125	430	270	225	8xΦ25	26	500	95.7
150	500	305	260	12xΦ25	28	550	133.3
200	560	350	305	12xΦ25	30	630	296.1
250	660	430	380	12xΦ27	34	725	339.1
