Marine Bronze Gate Valve JIS F7367 5K
1. Brief Introduction:
Marine bronze gate valve is rising stem type gate valve.
2. Standard:
Design Standard: JIS F7367-1996
Test Standard: JIS 7400-1996
Flange Size as Per JIS B2220-5K
3. Inspection:
Hydraulic Test Pressure:
Body: 1.05 Mpa
Seat: 0.7 Mpa
4. Main Material:
Part Name | Material Name | Material Mark |
Body | Bronze | BC6 |
Bonnet | Bronze | BC6 |
Disc | Bronze | BC6 |
Stem | Brass | C3771BD |
Gasket | Non-asbestos |
5. Marine Bronze Gate Valve JIS F7367 5K Main Data for Drawing (mm):
IMPA CODE | Size | L | D | C | Number of Bolt Hole | h | t | H | D2 | KG |
750951 | 15 | 90 | 80 | 60 | 4 | 12 | 9 | 175 | 80 | 2.29 |
750952 | 20 | 100 | 85 | 65 | 4 | 12 | 10 | 200 | 100 | 2.98 |
750953 | 25 | 110 | 95 | 75 | 4 | 12 | 10 | 220 | 125 | 4.1 |
750954 | 32 | 130 | 115 | 90 | 4 | 15 | 12 | 250 | 125 | 5.79 |
750955 | 40 | 140 | 120 | 95 | 4 | 15 | 12 | 290 | 140 | 7.78 |
