Marine Cast Steel Vertical Storm Valve JIS F3060 10k
Marine Cast Steel Vertical Storm Valve JIS F3060 10k;
1.Test standard:JISF7400.
2.End standard:JISB2210.
3.End type:Flange.
4.PN:10k.
5.DN:50mm-200mm.
6.Main material:
- Body/Bonnet:ZG230-450;
- Seat:SS410/BC6;
- Stem:SS410/BC6;
- Disc:SS410/BC6.
7.Application:Seawater and freshwater piping.
8.Function:Such valves are used for discharging seawater or freshwater and preventing refluence.
9.Specification of Marine Cast Steel Vertical Storm Valve JIS F3060 10k:
| IMPA | Type | DN | Face to face/L(mm) | Flange diam./D(mm) | Flange pitch/C(mm) | Flange hole/n*d(mm) | Weight/kg |
| 754241 | F3060 10k Vertical | 50 | 210 | 155 | 120 | 4XΦ19 | 12.65 |
| 754242 | 65 | 240 | 175 | 140 | 4XΦ19 | 18.15 | |
| 754243 | 80 | 260 | 185 | 150 | 8XΦ19 | 23.76 | |
| 754244 | 100 | 280 | 210 | 175 | 8XΦ19 | 32.56 | |
| 754245 | 125 | 330 | 250 | 210 | 8XΦ23 | 47.96 | |
| 754246 | 150 | 360 | 280 | 240 | 8XΦ23 | 56.76 | |
| 754247 | 200 | 450 | 330 | 290 | 12XΦ23 | 88.11 |
