Marine Wafer Type Butterfly Valve JIS F7480 5k/10k
Marine Wafer Type Butterfly Valve JIS F7480 5k/10k:
1.Test standard:JISF7400.
2.End standard:JISB2220.
3.End type:wafer type.
4.PN:5k/10k.
5.DN:50mm-400mm.
6.Main material:
- Body/Bonnet:Cast Steel/Ductile Iron;
- Seat:NBR;
- Stem:SUS403;
- Disc:SUS304/BC6.
7.Application:Oil piping,water piping and gas piping.
8.Test pressure:
PN | 5k | 10k |
Body/Mpa | 1.03 | 2.06 |
Seat/Mpa | 0.76 | 1.47 |
9.Specification of Marine Wafer Type Butterfly Valve JIS F7480 5k/10k:
Marine Wafer Type Butterfly Valve JIS F7480 5k(handle＆worm)
DN/mm | D/mm | D1/mm | L/mm | N/mm | Weight/kg |
50 | 94 | 105 | 43 | 4xΦ15 | 7.8 |
65 | 117 | 130 | 46 | 4xΦ15 | 11 |
80 | 127 | 145 | 46 | 4xΦ21 | 15 |
100 | 152 | 165 | 52 | 8xΦ19 | 18 |
125 | 183 | 200 | 56 | 8xΦ21 | 24 |
150 | 213 | 230 | 56 | 8xΦ21 | 35 |
200 | 263 | 280 | 60 | 8xΦ23 | 57 |
250 | 327 | 345 | 68 | 12xΦ25 | 90 |
300 | 370 | 390 | 78 | 12xΦ25 | 121 |
350 | 414 | 435 | 78 | 12xΦ27 | 177 |
400 | 474 | 495 | 102 | 16xΦ25 | 220 |
Marine Wafer Type Butterfly Valve JIS F7480 10k(handle＆worm)
DN/mm | D/mm | D1/mm | L/mm | N/mm | Weight/kg |
50 | 94 | 120 | 43 | 4xΦ21 | 7.8 |
65 | 117 | 140 | 46 | 4xΦ21 | 11 |
80 | 127 | 150 | 46 | 8xΦ21 | 15 |
100 | 152 | 175 | 52 | 8xΦ21 | 18 |
125 | 183 | 210 | 56 | 8xΦ25 | 24 |
150 | 213 | 240 | 56 | 8xΦ25 | 35 |
200 | 263 | 290 | 60 | 12xΦ23 | 57 |
250 | 327 | 355 | 68 | 12xΦ25 | 90 |
300 | 370 | 400 | 78 | 16xΦ27 | 121 |
350 | 414 | 445 | 78 | 16xΦ27 | 177 |
400 | 474 | 510 | 102 | 16xΦ29 | 220 |
