MARINE PRESSURE TRANSMITTER

Introduction

YSZK model pressure transmitter is to measure pressure of kinds of medium of liquids, gas in ship and other industrial equipments.

Main Technical Specification:

Power valtage: DC 24V;

Measuring accuracy: ±0.5%FS;

Working temp.: -20~60℃;

Output signal: DC 4~20mmA(tow wires HART);

Protection: IP66;

Over load: 2.5 time of full range;

Press connection size: M20X1.5, G1/4', G1/2';

Explosion proof Ex ia II CT4~T6;

Ex d II CT4~T6.
